12"x24" Surface Grinder w/ Kanetsu Chuck
12" x 24" Okamoto Surface Grinder w/ Kanetsu Chuck
Specification:
Nominal Grinding Capacity: 12" x 24"
Maximum Height Under 12" Wheel: 13.6"
Table Speed, Infinitely Variable: up to 82 FPM
Max. Longitudinal Table Movement: 29.5"
Auto Cross Feed Increment: 0.002" To .80"
Auto Continuous Crossfeed: 4 - 40 IPM
Crossfeed, Manual, Hand Feed Per Rev: 0.25"
Grad. Of Handwheel: 0.001"
Max. Crossfeed: 13.4"
Auto Incremental Downfeed Increments: 0.00005" To .0015"
Power Rapid Wheel Positioning Rate: 16 IPM
Spindle Motor: 5 HP
Wheel Size: 12" X 1.5" X 5"
Approximate Dimensions For Operation: 108" X 76"D X 70"H
Approximate Machine Weight: 5,500 lbs
Specifications subject to verification
Equipped With:
Kanetsu Magnetic Chuck
