| X-Axis | 19.7" | 500.38 mm |
| Y-Axis | 19.7" | 500.38 mm |
| Z-Axis | 19.7" | 500.38 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 40 | 40 |
| Taper | CT 40 | CT 40 |
| Pallet-W | 19.7" | 500.38 mm |
| Pallet-L | 19.7" | 500.38 mm |
| # Axis | 3 | 3 |
Enshu JE50S CNC Horizontal Machining Center
New: 2007
Specifications:
Travels:
X-Axis: 19.7"
Y-Axis: 19.7"
Z-Axis: 19.7"
Pallet Size: 19.7" x 19.7"
Maximum Workpiece Weight: 880 Lbs
Axes: 3
Pallet Indexing: 1 Degree
Spindle Taper: CT 40
Spindle Speed: 12000 RPM
Motor: 20 HP
Tool Changer: 40 ATC
Max Tool Length: 13.78"
Max Tool Diameter: 2.95"
Rapid Traverse Rate: 2,362 IPM
Equipped With:
Fanuc 18iM CNC Control
1 Degree Pallet
40 Tool ATC
Coolant Thru Spindle
Spindle Chiller
Helical Cutting
Up to 99 Fixture Offsets
This equipment is currently unavailable. Similar equipment available now is shown below.
