2001 MAKINO A99 | Machining Centers, Horizontal

Makino A99 CNC Horizontal Machining Center
New: 2001

Specifications:
Travels:
  X-Axis:                                39”
  Y-Axis:                                39”
  Z-Axis:                                37”
Pallet Size:                         31.5” x 31.5”  (2)
Tool Changer:                   40 ATC
Spindle Speed:                 12,000 RPM
Spindle Motor:                 40 HP
Spindle Taper:                  CAT 50

Equipped With:
Makino Pro 3 Control
1000 PSI Thru Spindle Coolant & Air
Tool Life Monitoring
1 Degree Table Indexing
Tecnomagnete Model C1706 HD50 Tombstone Style Electro Permanent Magnetic Chuck w/ Controller
High Earth Chain Model EEPM 6080 Electro-Permanent  Magnetic Chuck w/ EEPM-C4 Controller
Spindle Nozzle Coolant
AC & Spindle Load Monitor
Spare Tool Selection
Part Program Storage
Splash & Chip Shield
Overhead Shower Coolant System
Random Pallet Selection
Rigid Tapping
Door Interlocks
Air Dryer
Drag Type L/U Conveyor
GI Control w/ Super GI
Helical Interpolation
High Speed Skip Function
Data Server
